Wipcool P08J Condensate Atomiser
Condensate atomiser for split systems with a cooling capacity of up to 6.6 kW, for use where draining condensate into the sewer or outside the building is difficult. Sprays condensate as a fine mist through two nozzles.
- Condensate sprayed as a mist
- Float switch inside or separate
- Automatic start and stop
- Built-in spirit level
- 24-month warranty
- Warranty service in Poland
- Service by the distributor in the country of purchase
The P08J disperses condensate from an air conditioner as a fine mist, reducing water dripping from the unit. It is useful where draining condensate into the sewer, a drain or outside the building is difficult or undesirable. It is designed for split systems and has a flow rate of 8 l/h with two nozzles.
Condensate flows by gravity into a tank with a float switch, which can be installed inside or outside the housing. The atomiser pumps water through an Ø8 mm outlet hose to two metal nozzles; it switches on when the start level is reached and switches off when the water level drops.
In the box
- Metal spacerNot included in the first version of the P08J
- Ø8 mm polyamide outlet hose
- Ø8 mm inlet hose
- T-pieceY-piece in the first version of the P08J
- 90° elbowNot included in the first version of the P08J
- Metal nozzle2 pcs.
- Condensate hose connector2 pcs.
- 25 × 16 mm rubber reducer
- Adhesive hook-and-loop strip for mounting the float switch
- 10 cm cable tie3 pcs.
- Rubber anti-vibration pad
- Grey flexible connector
- Mounting plate
- Screws2 pcs.
- Wall plugs2 pcs.
- Air vent
- 6 mm reducer
- Blanking plug
Technical specifications
| Power supply | 230 V |
| Max. flow | 8 l/h (2 nozzles) |
| Operating pressure | 1,5 bar |
| Cooling capacity | 6,6 kW |
| Float chamber capacity | 35 ml |
| Noise level at 1 m | 23 dB (A) |
| Operating temperature | 0–50 °C |
| Power consumption | 15 W |
| Dimensions (L × W × H, mm) | 157 × 75 × 126 |
| Unit type | Wall-mounted split |
| Ingress protection rating | IPX4 |
| Protection class | II |
| Nozzle diameter | Ø0.4 mm |
| Outer pack | 12 pcs. |
Features and equipment
This equipment must only be operated by qualified personnel. Read the user manual before first use.
