Mini Condensate Pumps
P130
Wipcool P130 Condensate Pump
Condensate pump with a flow rate of up to 130 l/h, mounted below a split, ducted or cassette air conditioner, for dirty and oily water. Max. head up to 3.5 m.
- No float switch
- Centrifugal pump
- For dirty and oily water
- Flow up to 130 l/h
- 24-month warranty
- Warranty service in Poland
- Service by the distributor in the country of purchase
Key parameters
130l/h
Max. flow
3,5m
Max. head
do 44kW
AC cooling capacity
25dB(A)
Noise level at 1 m
The P130 is a high-flow condensate pump mounted on a mounting plate below the air conditioner, on the left or right side of the indoor unit. It removes condensate from split, ducted and cassette air conditioners, provided the condensate drains into its tank by gravity. The pump outlet fits 6 × 9 mm hose. The pump has no alarm line.
For dirty and oily water
The high-performance centrifugal pump also removes dirty and oil-contaminated condensate.
No float switch, with a limit switch
A limit switch replaces the float switch, reducing the number of components prone to failure.
In the box
- P130 Condensate Pump
- Mounting plateFor mounting the pump on the wall
- Wall plugs2 pcs
- Screws2 pcs
- Power cable
- User manual
Technical specifications
| Power supply | 230 V |
| Max. head | 3,5 m |
| Max. flow | 130 l/h |
| Tank capacity | 650 ml |
| Cooling capacity | 44 kW |
| Noise level at 1 m | 25 dB (A) |
| Operating temperature | 0–50 °C |
| Dimensions (L × W × H, mm) | 186 × 111 × 131 |
| Unit type | Wall-mounted split, Ducted / cassette |
| Power consumption | 10 W |
| Protection rating | IPX4 |
| Alarm line | No |
| Carton quantity | 12 pcs |
Features and equipment
Forced air-cooled motor
Backflow protection
Spirit level on the housing
Red power LED
Removable lockable tank, inlet filter
Mounting plate screwed to the wall
CAUTION
This equipment must only be operated by qualified personnel. Read the user manual before first use.
Documents in: EN
