Wipcool AWD12 Cable Detector

Detector for locating metal and live cables in walls, ceilings and floors, and wood behind plasterboard. It shows the depth of detected metal and distinguishes magnetic from non-magnetic metal.

  • Metal, AC cables and wood
  • Metal depth on the display
  • Identifies magnetic metal
  • Edge and centre of wood
  • 24-month warranty
  • Service by the distributor in the country of purchase
Key parameters
120mm
Depth: ferrous metal
100mm
Depth: copper
50mm
Depth: AC cable 220 V 50 Hz
38mm
Wood, deep mode
Net list price
Request a quote
Request a quote
Where to buy

The AWD12 works in three modes: metal, live AC cables and foreign objects, mainly wood. It detects ferrous metal to a depth of 120 mm, copper to 100 mm, live cables to 50 mm and wood to 38 mm in deep mode. A signal strength bar, the ‘Center’ icon and three-colour LEDs indicate when the object is directly beneath the centre of the detector.

Metal type symbol on the display
Magnetic and non-magnetic metal symbols usually let you tell a steel bar from a copper pipe or cable, while the absence of both symbols most often indicates a metal alloy.
Metal depth on the display
During scanning the detector shows the depth of the detected metal - most accurately for a steel bar or copper pipe 18 mm in diameter, and as an approximate value for other objects.
Edges and centre of the object
In foreign object mode the ‘Edge’ and ‘Center’ icons mark the edges and centre of a timber stud behind plasterboard or plywood.

In the box

  • AWD12 Cable Detector
  • User manual
